RETIRED ›
This product is no longer available and has been replaced by: REGSS-6A-12V. Some accessories, replacement parts, or services may still be available.
This product is no longer available and has been replaced by: REGSS-6A-12V. Some accessories, replacement parts, or services may still be available.
| Services Available |
|---|
Overview
The REG5 allows you to connect a solar panel 12Vdc and a battery 12Vdv to prevent an overcharge the battery.
Read MoreImages
Technical Description
Supply voltage from the solar panel is connected to the Solar Cell terminal. Regulated voltage to charge the datalogger’s sealed rechargeable power supply are sourced from the Battery terminal.
Compatibility
Datalogger Considerations
Compatible Contemporary Dataloggers
| CR200 Series | CR800/CR850 | CR1000 | CR3000 | CR5000 | CR7X | CR9000X |
 |
|
|
|
|
|
Compatible Retired Dataloggers
| CR500 | CR510 | CR10 | CR10X | 21X | CR23X | CR9000 |
|
|
|
|
|
|
|
Note:
Mounting holes are compatible with an imperial enclosure only
Specifications
- Input voltage solar cell panels: 14 - 30 V/DC open circuit voltage
- Nominal voltage: 12 Vdc
- Maximum input current: 6 A, short-time till 5 min: 10 A
- Inrush voltage: battery voltage approx. 13,4 V
- Interrupting voltage: battery voltage > approx. 14,4 V
- Displays: 1 LED for “CHARGING”, 1 LED for “BATTERY FULL”
- Own power consumption: < 2,5 mA (LED switched on)
